Doran 360HD - Stored Alarm Information

DORAN MFG. LLC  2851 Massachusetts Ave  Cincinnati, OH 45225  866-816-7233 
Doranmfg.com
23
 Press and hold the P button for 30 seconds. This
will erase all sensor information and return the
monitor to its factory defaults.
3. Stored Alarm Information
The DORAN 360HD has the ability to store the last 32
alarm faults that have occurred. They can’t be erased; they
can only be replaced by newer, more recent alarms. This can be useful if a history of
alarms is necessary. Monitoring the faults and when they
occur can be a useful tool for the over the road trucking
industry.
To enter this function, press the P and S buttons together
for 3 seconds. A number 0 will be displayed on the screen
(see Figure 6-1). If no other buttons are pressed within 1
second the monitor will automatically start to show the last
alarm and then will show up to the last 32 alarms that have
occurred from the most recent to the oldest. You can
select the next alarm by using the right arrow key.
The display will show as follows:
Figure 6-2 Actual pressure for the alarm
Figure 6-3 M07 is for the 7
th
month or July.
Figure 6-4 d04 is for the 4
th
day of the month
Figure 6-5 Y06 is for the year 2006
Figure 6-6 h14 stands for 2:00 PM (24-hour clock)
Figure 6-7 m33 Stands for 33 minutes
When you have finished checking the alarm history the
P and S buttons can be pressed together for three
seconds to return to the normal operation mode.
Fi
g
ure 6-1
Fi
g
ure 6-3
Fi
g
ure 6-4
Fi
g
ure 6-5
Fi
g
ure 6-6
Fi
g
ure 6-7
Fi
g
ure 6-2
