ED100 / ED250 SERVICE MANUAL
—
15
Terminal board layout
Use terminal board connection diagram below as reference for
wiring of activators, locking devices, safety sensors and other
accessories.
Electric shock hazard! 115VAC branch circuit
disconnect for the ED100 / ED250 must be OFF
while making these wiring connections!
Cables connect to applicable connection board plugs.
These keyed plugs are inserted into their keyed sockets on
terminal board.
Devices must be connected to their respective sockets prior to
powering operator.
Use documentation provided with each device to
determine wiring interface to connection board.
97 98 99 30 31 32 34 33 3335
1
36
1
4
4a
3
BA
1
57 57a
142
3
141
3
1
15
17
3
111
13 3
43 3646362
1G
3
+ 24 V Signal input
0 V
+ 24 V
COM
Locking relay
max. 1 A / 48 V DC/AC
NO
NC
0 V
Locking feedback contact
0 V
+ 24 V Signal input
0 V 0 V
+ 24 V
0 V
Signal input
0 V
Partial Open
Permanent Open
Exit Only
AUTOMATIC
Off
NC
NO
COM
0 V
Signal input Test output + 24 V 0 V Signal input Test output + 24 V 0 V
OUTPUT
Night
trigger
Interior
activation
inputs
Exterior
activation
inputs
Safety sensors
X5X4
X3
X6 X9 X1 X7
Program switches
Maximum current load: 1.5 A
+ 24 V
DCW Bus
X8
0 V
Connection diagram
X10
24 VDC
Class II
Smoke detectors
Door
Status
Indicates slot in socket at
terminal location is keyed with
a red insert.
The assigned plug for the
socket has tab in the same
location broken off to allow
insertion of the plug into its
socket.
This insures that only the
correct plug can be inserted
into its assigned socket.
Green LEDYellow LED
Red LED
Jumpers:
To enable the operator
unit to be commissioned,
jumpers are installed at
the factory between the
following terminals:
4 & 4a
15 & 3*
11 & 3*
*Remove jumpers if
safety sensors are
installed.
Emergency
close
8 - 24 AC/DC + 5% Night bank
Wet
Swing side Approach side
Dry
Plug included in
DCW upgrade card
scope of delivery
Plug included in
fire protection
upgrade card
scope of delivery
10 System accessories – electrical interface
