ED100 / ED250 SERVICE MANUAL
—
30
Parameter detail
Parameters / Display Value range
Unit
factory setting
= bold
Explanation
35. Power assist function
activation angle
1 – 5 Degrees
3
■ Adjustment of door activation angle for Power Assist function
(hF).
■ Higher hA settings result in better spring force compensation for
easier manual opening.
■ Power assist function is more sensitive the smaller the activation
angle value.
36. Power assist function
(force adjustment) (v1.7)
0 – 10 0 ■ hF is force adjustment setting for Power assist function.
The greater the adjusted value, the easier the door can be
manually opened from activation angle hA.
■ Power assist function is available only in door closer mode
(hd=1 - manual mode).
■ Power assist function is enabled when hF is set to any value but
"0".
■ Power assist function hF is enabled when power assist activation
angle hA is reached.
■ Power assist function is not available when operator is switched
OFF, or a smoke detectors or an emergency stop pushbutton
has been triggered.
■ Door may open unintentionally if Power assist support function
is adjusted too high!
37. Support for manual
mode in closed
position (v1.9)
0 – 10 0 ■ hS is force adjustment setting for Power assist function support
with door in closed position at power assist activation angle hA.
■ hS is available only in door closer mode (hd=1 - manual mode).
■ The greater the value, the easier it is to open door manually-
from closed position.
38. Upgrade card – Fire
protection
ED 100 (red)
ED 250 red /
transparent
0 -not available
1 available, but
not activated
2 active
3 upgrade card
removed,
function no
longer available
■ When ED 100 or ED250 is installed at smoke / fire doors with
application in preventative fire protection, upgrade card Fire
Protection is required for compliance with guidelines for hold-
open devices.
■ In addition to its smoke detector connection (as monitored
current loop), this card also offers a manual reset function (by
opening door), a full energy function, and system may be
triggered at door.
Note: no additional Full energy upgrade card is required.
39. Upgrade card –
Full-Energy
ED 100 (blue)
ED 250 blue /
transparent
0 -not available
1 available, but
not activated
2 active
3 upgrade card
removed,
function no
longer available
■ Provides higher driving speeds than low-energy version
■ ED 100: driving speed can be increased to a maximum of
50º / second.
■ ED 250: driving speed can be increased to a maximum of
60º / second.
■ Full energy mode will require door swing path to be monitored
by safety sensors
