ED100 / ED250 SERVICE MANUAL
—
31
Parameter detail
Parameters / Display Value range
Unit
factory setting
= bold
Explanation
Upgrade card – Professional
green (40. through 44.)
40. Flip-Flop function
0 -not available
1 available, but
not activated
2 active
3 upgrade card
removed,
function no
longer available
■ In standard mode, operator opens door after a Night/Bank
pulse has been triggered (via key switch) and closes it on
expiration of hold-open time.
■ Flip-Flop function (set to 2): the door opens and remains in
PERMANENT OPEN position as soon as Night/Bank function is
triggered at respective input.
■ Door will close when Night/Bank function is activated again.
■ Hold-open period in PERMANENT OPEN position is not
limited, and standard hold-open time is available at all other
activator inputs.
41. Extended hold-open
time
0 -not available
1 available, but
not activated
2 active
3 upgrade card
removed,
function no
longer available
■ Hold-open time of up to 30 seconds is integrated into standard
system, and is sufficient for most applications.
■ Extended hold-open time (set to 2): A hold open time of up
to 180 seconds may be achieved by use of the Full-Energy
upgrade card.
42. Nurse-Bed
function
0 -not available
1 available, but
not activated
2 active
3 upgrade card
removed,
function no
longer available
■ Only for double door systems.
■ Nurse-bed function controls two doors separately.
■ Activator connected to the external detector initiates active door
to open. Resulting door passage is sufficiently wide to allow
people to use door.
■ Other activator (one that is connected to internal detector) is
used to open door to full opening width. In this case, both doors
are open so that full passage width is accessible.
43. Upgrade card –
Barrier-free toilet
0 -not available
1 available, but
not activated
2 active
3 upgrade card
removed,
function no
longer available
■ With upgrade card, required special functions for barrier-free
toilet are allocated to specific inputs and outputs of control
unit. This facilitates their connection of the respective devices.
■ System requires an electric strike, and a motor lock or similar
device to keep door closed.
■ Barrier free toilet door is equipped with a lever handle on the
inside and a knob on the outside. Door may only be opened
from the inside and from the outside only with a corresponding
key.
■ Large surface pushbuttons are installed on inside and on outside
of toilet.
■ A status indicator "vacant/occupied" is installed on outside of
toilet and an "occupied" light is installed on inside of the toilet.
44. Upgrade card –
DCW (yellow)
0 -not available
1 available, but
not activated
2 active
3 upgrade card
removed,
function no
longer available
Upgrade card provides operator with a DCW bus connection.
45. Configuration of
COM1 interface
(upright connector)
0 – 1 0 Interface is programmed for communication with DORMA hand-
held terminal.
1
DORMA TMS software
