ED50/ED100/ED250 09-2021DL4617-003
dormakaba ED50/ED100/ED250 OHC Header
Setup and Troubleshooting Instructions
Chapter 11
Fig. 11.8.3 Overhead arm at zero degree closed position.
Fig. 11.8.4 Overhead arm at 70 degree position for door installation;
LH inswing example
Fig. 11.8.5 LH outswing
Fig. 11.8.6 RH outswing
Header cover
Fig. 11.8.7 LH inswing
Header cover
Fig. 11.8.8 RH inswing
.. Door overhead arm configurations.
