dormakaba Mounting instructions Safety
1.1.2 Further labeling
1
The picture number in the
text document refers to an
illustration in the picture
section of the mounting
instructions
1. 2.
Step-by-step graphics
1 2
Position numbers of
components
6
Reference to chapter or
page number
1.2 Glossary
1
(1) Rebate dimensions
(2) Lintel mounting (standard mounting)
(3) Lintel depth
(4) Door hinge
(5) Main closing edge
(6) Hinge side
(7) Opposite hinge side
2 Safety
For your safety, it is important to follow all
instructions provided.
Incorrect mounting may lead to serious
injuries.
The use of control elements, settings or
procedures, which are not described in this
documentation, may cause electric shocks,
hazards posed by electrical voltages/
currents and/or hazards posed by
mechanical processes.
2.1 Intended use
The PORTEO is an electromechanical
operator and is used exclusively for opening
and closing swing doors indoors with a
permissible door leaf weight of up to 140kg.
The PORTEO is not suitable for use in
escape routes, on fire protection doors (fire/
smoke protection doors) or in outdoor areas.
The maximum cable length of external
components must not exceed 30 m.
The door leaf is connected via slide rail or
optional scissor arm.
2.2 Basic warnings
DANGER
Danger to life through electric
current
Works on electrical units must
only be carried out by qualified
electricians.
• Before starting work on
electrical units and equipment,
establish a voltage-free state
and maintain this state while
carrying out the work.
• Never insert metal objects into
the openings of the PORTEO.
Doing so would risk an electric
shock.
• If the PORTEO is mounted on
a metallic door leaf, the door
leaf must be sufficiently
grounded.
CAUTION
Risk of injury by crushing
On doors with operators there is
a risk of crushing and shearing
on slide rail levers, rods and
closing edges
• Inform the door’s facility
operator of the danger.
• Do not let children play with the PORTEO
or its regulating and control equipment.
• Keep remote controls out of reach of
children.
