30 DR
®
SNOW BLOWER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – PRO 24 MAIN ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 40278 Nut, Jam, M8
2 40279 Nut, Jam, M8
3 40086 Gimball, Shifter
4 40315 Nut, M8x1
5 40087 Connector Bar, Shifter
6 40333 Washer, 8mm ID X 22mm OD X 2mm
7 40088 Adapter Plate, Handlebars
8 40310 Bolt, M8x55
9 40290 Bolt, M6x16
10 40089 Cover, Belt
11 40090 Guide, Belt
12 40283 Bolt, 5/16-24x3/4
13 40344 Washer, Flat, 8mm
14 40091 Chute Assembly
Ref# Part# Description
15 40092 Shovel
16 40334 Washer, Chute Worm Gear
17 40093 Spacer, Chute Worm Gear
18 40094 Worm Gear, Chute
19 40095 Shaft, Core, Worm Gear
20 40096 Connector Tube, Worm Gear
21 40319 Pin, Cylinder, 3mmx18mm
22 40335 Washer, Chute
23 40097 Bracket, Worm Gear Chute
24 40347 Washer, Spring, 6mm
25 40325 Screw, M6x16
26 40098 Block, Chute
27 40099 Belt, Auger
28 40342 Washer, Flat, 6mm
To Next Page
