DR PRO-24 User Manual

40 DR
®
SNOW BLOWER
Parts List – PRO-24 COLLECTOR ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 40194 Collector Housing
2 40195 Collector Skid Shoe
3 40196 Collector Skid Shoe
4 40281 Nut
, M8
5 40338 Washer
, 8mm
6 40304 Bolt
, M8x25
7 40299 Bolt
, M8x16
8 40197 24in Shave Plate
9 40198 Bearing Cover
10 40199 Bearing
, Collector
11 40327 Screw
, M6x16
12 40225 Ball Bearing Sb204
13 40200 Auger
, Right
14 40293 Bolt
, M6x25
15 40201 Bushing
, Auger
16 40202 Seal Ring 22x30x7
17 40203 Worm Gear Housing
, Right
18 40204 Shaft
, Auger Output
19 40285 Bolt
, M10x15
20 40317 Pin
, Cotter Auger Drive
21 40311 Bolt
, Shear Auger
22 40205 Gasket
, Paper
23 40206 Sleeve
, Shaft 22mm Dia
24 40349 Washer
, Worm Gear
25 40207 Worm Gear
26 40208 Key
, Flat A6x6x18
Ref# Part# Description
27 40209 Ball Bearing 6001
28 40210 Housing Worm Gear Left
29 40294 Bolt
, M6x30
30 40313 Nut
, Jam M6
31 40211 Auger
, Left
32 40212 Oil Cup
, M6
33 40213 Bracket
, Right Support
34 40343 Washer
, Flat 6mm
35 40320 Pin
, Cylinder 6mmx14mm
36 40214 Shaft
, Auger Worm
37 40215 Bracket
, Left Support
38 40216 Ball Bearing 6004
39 40217 Sleeve
, Auger Shaft
40 40218 Ball Bearing 51104
41 40219 Seal Ring-20x35x7
42 40296 Bolt
, M6x35
43 40220 Impeller
44 40330 Screw
, Self-Taping 4.2x9.5
45 40221 Bracket
, Shovel
46 40279 Nut
, Jam M8
47 40222 Pulley
, Auger
48 40331 Washer
, 8mm Drive
49 40284 Bolt
, Left Hand Thread M10x25
50 40223 Key
, Flat 6x20
51 40224 Cover Auger Drive

DR PRO-24 Specifications

General

Brand	DR
Model	PRO-24
Category	Snow Blower
Language	English
