38 DR
®
SNOW BLOWER
Parts List –PRO-28, PRO XL-30 and PRO MAX-34 DRIVE ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 40286 Bolt, M10x25
2 40129 Handlebar Base
3 40130 Plate Handlebar Connector
4 40288 Bolt, M10x25
5 40289 Bolt, M6x12
6 40131 Strut, Frame Assembly
7 40193 Strut, Friction Disc Support
8 40291 Bolt, M6x20
9 40133 Pulley Seat, Frame
10 40134 Sleeve, Shaft
11 40135 Drive Engagement Wire
12 40136 Pulley Wire, Drive Engagement
13 40313 Nut, Jam M6
14 40138 Plate Connector Drive
15 40301 Bolt, M8x20
16 40308 Bolt, M8x40
17 40139 Engine Seat
18 40279 Nut, Jam M8
19 40238 Engine (Pro-28)
40266 Engine (Pro XL-30)
40272 Engine (Pro MAX-34)
20 40141 Belt, Pro
21 40239 Wheel, Drive
22 40240 Washer, Drive
23 40241 Pulley, Drive
24 40331 Washer, 8mm Drive
25 40282 Bolt, 5/16-24x1-1/4
26 40144 Transmission Box Assembly
27 40292 Bolt, M6x20
28 40145 Connector Shift
29 40146 Sleeve, Plastic
30 40147 Shift Fork
31 40290 Bolt, M6x16
32 40148 Bearing Seat, Drive
33 40149 Ball Bearing 6200
34 40150 Circlip 25
35 40151 Bearing, Shift
36 40152 Sleeve 15x20x15
37 40153 Seat Friction Wheel
38 40154 Gear, Small Drive
39 40155 Friction Disc Wheel
40 40317 Pin, Cotter Auger Drive
41 40156 Shaft, Hexagon Drive
42 40157 Shaft, Transit
43 40158 Sprocket, Large Drive
44 40159 Sprocket, Small Drive
45 40160 Sleeve, 12x15x8
Ref# Part# Description
46 40161 Chain, Drive 085-32
47 40242 Tire, 15x4.8-7 (Pro-28)
40267 Tire 16x4 8-8-Sb1 (Pro XL-30, Pro MAX-34)
48 40163 Clip Wheel
49 40243 Rim
50 40298 Bolt, M8x16
51 40165 Bearing Seat, Axle
52 40278 Nut, Jam M8
53 40166 Ball Bearing 6205
54 40167 Sleeve, Shaft 25x34x16
55 40168 Shaft, Short Drive
56 40169 Key-Flat 6x4x45
57 40170 Sleeve, Bronze 1
58 40171 Differential Di300p (Pro-28, Pro XL-30)
40273 Differential Di500 Pro MAX-34)
59 40172 Sleeve, Bronze 2
60 40173 Shaft, Long Drive
61 40174 Connector, Auger Tension
62 40340 Washer, Flat 12mm Dia
63 40341 Washer, Spring 12mm
64 40175 Block, Connector Tension
65 40305 Bolt, M8x30
66 40176 Pulley, Auger Tension
67 40244 Plate, Auger Tension
68 40309 Bolt, M8x45
69 40178 Plate, Auger Tension
70 40179 Bushing, Auger
71 40180 Pulley, Large Tension Auger
72 40181 Pad, Pulley Tension
73 40182 Pulley, Drive
74 40292 Bolt, M6x20
75 40183 Bearing Seat, Delta
76 40184 Bearing Ball 6002
77 40185 Spring, Auger Tension
78 40186 Bracket, Drive
79 40187 Sleeve, Support Friction Disc
80 40298 Bolt, M8x16
81 40312 Nut, Jam M12
82 40188 Spring, Auger Brake
83 40323 Rivet, 4x12
84 40189 Block, Auger Brake
85 40190 Transmission Cover
86 40191 Bracket, Drive Cable
87 40316 Pin, Cotter 1.5x25
88 40192 Spring, Friction Disc
