DR PRO-24 User Manual

42 DR
®
SNOW BLOWER
Parts List – PRO-28, PRO XL-30 and PRO MAX-34 COLLECTOR ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 40245 Collector Housing, (Pro-28)
40268 Collector Housing (Pro XL-30)
40274 Collector Housing Pro MAX-34)
2 40350 Drift Cutter
3 40351 Nut
, Wing M8 Plastic
4 40196 Collector Skid Shoe
5 40344 Washer
, Flat 8mm
6 40278 Nut
, Jam M8
7 40195 Collector Skid Shoe
8 40279 Nut
, Jam M8
9 40299 Bolt
, M8x16
10 40300 Bolt
, M8x18
11 40246 Shave Plate
, (Pro-28)
40269 Shave Plate
, (Pro XL-30)
40275 Shave Plate
, (Pro MAX-34)
12 40247 Bearing Seat
13 40248 Bearing Sb205-
14 40249 Bearing Seat
, 205
15 40250 Auger
, Right (Pro-28)
40270 Auger Right
(Pro XL-30)
40276 Auger Right
(Pro MAX-34)
16 40345 Washer
, Flat 8mm
17 40251 Oil Cup
, M8
18 40252 Grease Cap-
19 40321 Pin
, Shear
Ref# Part# Description
20 40253 Housing Worm Gear
21 40313 Nut
, Jam M6
22 40347 Washer
, Spring 6mm
23 40254 Impeller
24 40297 Bolt
, M6x40
25 40295 Bolt
, M6x30
26 40255 Bracket
, Right Support
27 40256 Bracket
, Left Support
28 40257 Auger Left
, (Pro-28)
40271 Auger Left
(Pro XL-30)
40277 Auger Left
(Pro MAX-34)
29 40348 Washer
, Spring 8mm
30 40303 Bolt
, M8x20
31 40303 Bolt
, M8x20
32 40304 Bolt
, M8x25
33 40330 Screw
, Self-Taping 4.2x9.5
34 40221 Bracket
, Shovel
35 40258 Bearing Seat
36 40225 Ball Bearing Sb204-
37 40259 Pulley
, Auger
38 40339 Washer
, Flat 10mm
39 40287 Bolt
, M10x25
40 40260 Key
, Flat A 6x20
41 40346 Washer
, Plastic

DR PRO-24 Specifications

General

Brand	DR
Model	PRO-24
Category	Snow Blower
Language	English
