32 DR
®
SNOW BLOWER
Parts List – PRO-28, PRO XL-30 and PRO MAX-34 Main assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 40279 Nut, Jam M8
2 40086 Gimball, Shifter
3 40315 Nut, M8x1
4 40087 Connector Bar, Shifter
5 40278 Nut, Jam, M8
6 40333 Washer, 8mm ID X 22mm OD X 2mm
7 40088 Adapter Plate, Handlebars
8 40310 Bolt, M8x55
9 40290 Bolt, M6x16
10 40089 Cover, Belt
11 40090 Guide, Belt
12 40302 Bolt, M8x20
13 40236 Chute Assembly
14 40092 Shovel
Ref# Part# Description
15 40334 Washer, Chute Worm Gear
16 40093 Spacer, Chute Worm Gear
17 40094 Worm Gear, Chute
18 40095 Shaft, Worm Gear Core
19 40096 Connector Tube, Worm Gear
20 40319 Pin, Cylinder, 3mmx18mm
21 40335 Washer, Chute
22 40097 Bracket, Worm Gear Chute
23 40347 Washer, Spring, 6mm
24 40325 Screw, M6x16
25 40098 Block, Chute
26 40237 Belt-Auger (PRO-28)
26 40265 Belt-Auger (PRO XL-30 and PRO MAX-
34)
27 40342 Washer, Flat, 6mm
