34 DR
®
SNOW BLOWER
Parts List –HANDLEBAR ASSEMBLY (all models)
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 40100 Handle, Upper Right
2 40101 Control Panel
3 40278 Nut, Jam, M8
4 40332 Washer, Spring, 8mm
5 40102 Bracket, Spring
6 40307 Bolt, M8x40
7 40103 Cable, Control, Auger/Drive
8 40306 Bolt, M8x35
9 40316 Pin, Cotter, 1.5x25
10 40104 Lever, Shifter
11 40314 Nut, M10
12 40105 Handle, Shifter
13 40106 Lever, Chute Deflector
14 40107 Bumper, Handle, Rubber
15 40108 Spring, Handle Return
16 40109 Lever, Auger Handle
17 40336 Washer, 8mm
18 40326 Screw, M8x120
19 40110 Stopper, Cam Lever
20 40318 Pin, Cotter
21 40111 Cam, Right Lever
22 40112 Cam, Left Lever
23 40113 Spring, Stopper
Ref# Part# Description
24 40328 Screw, M8x60
25 40322 Rivet, 4x10
26 40114 Handle, Heated
27 40115 Lever, Drive Handle
28 40116 Bushing, Rubber
29 40117 Wire Harness, Switch
30 40118 Switch, Electrical
31 40119 Cable, Chute Deflector
32 40120 Spring, Lever Reset
33 40121 Handle, Chute Rotation
34 40122 Washer, Rubber, Chute
35 40123 Transmission Box, Chute
36 40124 Handle, Upper Left
37 40125 Shaft, Flexible, Chute
38 40324 Screw, M6x10
39 40343 Washer, Flat, 6mm
40 40126 Panel, Headlight Mount
41 40290 Bolt, M6x16
42 40127 Cover, Control Panel
43 40313 Nut, Jam, M6
44 40128 Light, Led
45 40329 Screw, Self-Taping, 3.5x16
