DR ROTO-HOG - Installing the Culti-packer

Assembling the Culti-packer
1. Position the Hook Assembly and line up the holes
with the Frame Assembly (Figure 18).
Frame
A
ssembly
Hook
A
ssembly
Hook
A
xle
2. Insert the Hook Axle so it is flush on both sides.
Figure 18
3. Insert two Hairpin Clips into the holes in the Hook
Axle (Figure 19).
Hairpin
Clip
Hook
A
xle
Figure 19
4. Install the springs onto the two Eye Bolts on the
Frame Assembly (Figure 20).
Springs
Eye Bolt
Figure 20
