DR ROTO-HOG User Manual

CHAPTER 3
SETTING UP YOUR ACCESSORY for the DR ROTO-HOG
POWER TILLER
This chapter outlines a few simple steps you will need to follow to set up and use your new DR ROTO-
HOG POWER TILLER OPTIONAL ACCESSORIES. If you have any questions at all, please feel free to
contact our Customer Service Representatives at our toll free number 1-800-DR-OWNER (376-9637).
SETTING UP YOUR DR POWER SPREADER
Unpacking the DR Power Spreader
Parts Supplied:
• Hopper/Frame Assembly
• Screen
• Vinyl Cover
• Hardware Package
• Impeller Shaft
• Deflector
• Mounting Bracket, R.H.
• Mounting Bracket, L.H.
• Impeller
• Motor Mount Assembly
Hopper/Frame
A
ssembly
Tools Needed:
• Pliers
Motor Mount
A
ssembly
1. Open the shipping container by pulling the staples out
with pliers and opening the top flaps (Figure 1).
2. Remove the contents to a flat open area (the M
Brackets are located under the bottom box flaps).
Open the cardboard that is wrapped around the Mo
ounting
3. tor
ware
4. (Figure 2).
Mount Assembly to remove the Motor Mount
Assembly, Vinyl Cover, Impeller Shaft and Hard
Package
See the unpacked “Major Components”
NOTE: Do not discard your packaging material until you are
fully satisfied with your new DR POWER SPREADER.
Figure 1
CALL TOLL FREE 1-800-DR-OWNER 5
