28 DR
®
ROTO-HOG™ POWER TILLER - OPTIONAL ACCESSORIES
ER 7
CHAPT
PARTS LIST AND SCHEMATIC DIAGRAMS
Parts List - DR POWER SPREADER
NOTE: Part numbers listed are available through Country Home Products.
Ref# Part# Description
01 234851 Hopper
02 234811 Plug, 1/4"
03 234761 Bolt, Hex, 1/4-20" x 2-1/4"
04 234791 Bolt, Hex, 1/4-20" x 2"
05 234911 Washer, Nylon
06 232891 Washer, 1/4 Std .312 X .734
07 233031 Nut, Hex 1/4-20 Nylock
08 234651 Clip
09 234641 Plate, Side
10 234731 Bushing, Hopper
11 234591 Plate, Guide
12 234711 Rivet, Pop, 3/16"
13 234681 Cable Assembly, Control
14 234621 Bracket, Control Mount
15 234751 Bolt, Carriage, 1/4"-20 x 1-3/4"
16 234801 Nut, Hex Sims, 1/4"
17 234701 Knob, Wing
18 234741 Washer, Star
19 234901 Impeller, Spreader
20 234871 Tube, Hopper Mount
21 234721 Bolt, Carriage, 5/16"-18/ x 1-3/4"
22 234891 Screen, Spreader
23 234661 Bracket, Mount RH
24 234671 Bracket, Mount LH
25 234861 Hairpin, Agitator
26 233081 Nut, Hex 5/16-18 Nylock
27 234881 Cover, Vinyl
28 232841 Bolt, Hex 1/4-20 X 3/4 G5
29 234831 Deflector, Rear
30 234821 Cover, Motor
Ref# Part# Description
31 234931 Washer, Lock. #10
32 232871 Washer, 5/16" Std .375 X .875
33 234581 Bracket, Angle
34 232951 Washer, SAE. #10
35 232851 Bolt, Hex 5/16-18 X 1 G5
36 234631 Shaft, Impeller
37 234601 Coupler, Impeller
38 234841 Seal, Motor Lip
39 234691 Pin, Cotter, 1/8" x 1-1/4"
40 234771 Bolt, Pan Slot, #8-32 x 1/2"
41 234921 Tie, Nylon
42 234611 Bracket, Motor Mount
43 234781 Motor, 12 Volt
44 232931 Bolt, Slotted, #10-32 X 5/8"
45 233021 Nut, Nylock, #10-32
46 234571 Bracket, Mounting
47 234971 Label, Spreader Operation
48 233721 Spreader Cable
