20 Instructions for use BiliLux
Overview
4.1.3 Rear view
A On/off switch
B Power cable receptacle
C Quick-connect plug (for connection to optional spring arm)
D RS-232 communication port
E Receptacle for radiometer cable
F USB port
4.2 BiliLux with optional spring arm
A Quick-connect for phototherapy light
B Release knob for phototherapy light
C Spring arm
D Cable clips
E Plug to connect to trolley pole or rail clamp
F Rail clamp for phototherapy light (to connect to 38 mm pole and DIN, Fairfield,
and GCX rails)
003
A
B
C
D
E
F
004
A
C
D
D
E
B
F
