Instructions for use BiliLux 73
Technical data
14.3 Environmental requirements
14.4 Electrical requirements
14.5 Noise requirements
14.6 RS-232 communication port
Operating conditions
Temperature 18 °C (64.4 °F) to 40 °C (104 °F)
Humidity 10% to 95% relative humidity, non-
condensing
Ambient pressure 1100 hPa to 700 hPa
Storage/transportation conditions
Temperature -20°C (-4°F) to 60 °C (140 °F)
Humidity 10% to 95% relative humidity, non-
condensing
Ambient pressure 1100 hPa to 500 hPa
Power requirements 100-240 V AC, 50/60 Hz, 0.42-0.22 A
Earth leakage current <500 µA
Noise level during normal operation 20 dB(A)
RS-232 communication port (output only) Only connect devices that fulfill the
requirements of the standard IEC
60950-1 on unearthed SELV circuits or
the requirements of the standard IEC
60601-1 on accessible secondary
circuits with max. 60 V DC nominal
voltage.
Type 9-pin Sub-D (female)
Configuration MEDIBUS.X
Dräger MEDIBUS.X, version 6.0 by the RS-232 port only
Baud rate 9600
Parity even
Data bits 8
Stop bits 1
For a detailed description of the interface protocol, please see these manuals:
MEDIBUS.X, Rules and Standards for Implementation (9052607) and MEDIBUS.X,
Profile Definition for Data Communication V1.n (9052608)
