Instructions for use BiliLux 75
Technical data
14.7.2 Distribution of irradiance
This measurement was performed at a vertical distance of 40 cm above a 30 cm x
50 cm bed surface. The values below are at the 100% irradiance setting.
14.8 Radiometer option requirements
14.8.1 Radiometer calibration graph
The radiometer is calibrated for measurement of light with the relative spectrum
shown in the graph.
2.07 2.11 2.19 2.15 2.07 10 cm
Ebi [mW/cm
2
]
(400-550 nm)
1.88 1.92 2.01 1.96 1.94 10 cm
2.07 2.21 2.31 2.24 2.22 10 cm
10 cm 10 cm 10 cm 10 cm 10 cm
Category Value
Accuracy +3%/-15%
Measurement output Average spectral irradiance, 460 nm to
490 nm
Relative irradiance
Wavelength (nm)
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
400 410 420 430 440 450 460 470 480 490 500 510 520 530 540 550
