Dräger Fabius plus XL User Manual

Supplement Fabius plus XL SW 3.n 43
Annex
Recommended separation distances
from wireless communication devices
To ensure that the full functional integrity of this
device is not compromised, there must be a
separation distance of at least 1.0 m (3.3 ft)
between this device and wireless high-frequency
communication equipment.
Annex
Form for daily checkout and pre-use checkout
The terminology for the O2 sensor has changed.
Immunity against Test level and required electromagnetic environ-
ment
Electrostatic discharge (ESD)
(IEC 61000-4-2)
Contact discharge: ±8 kV
Air discharge: ±15 kV
Fast transient electrical disturbances (bursts)
(IEC 61000-4-4)
Power cable: ±2 kV
Longer signal input lines/output lines: ±1 kV
Impulse voltages (surges)
(IEC 61000-4-5)
Voltage, external conductor – external conductor:
±1 kV
Voltage, external conductor – protective ground con-
ductor: ±2 kV
Magnetic fields at mains frequency
(IEC 61000-4-8)
50 Hz: 30 A/m
Voltage dips and short interruptions in the sup-
ply voltage
(IEC 61000-4-11)
Voltage dips of 30 % to 100 %, 8.3 ms to 5 s, different
phase angles
Radiated high-frequency disturbances
(IEC 61000-4-3)
80 MHz to 2.7 GHz: 3 V/m
Conducted high-frequency disturbances
(IEC 61000-4-6)
150 kHz to 80 MHz: 3 V, ISM bands: 6 V
Electromagnetic fields in the vicinity of wireless
communication devices
Various frequencies from 385 MHz to 5785 MHz:
9 V/m to 28 V/m
Calibration of the sensors
Remove the O
2 sensor from the cover of
the inspiratory valve.
Expose the O2 sensor to ambient air for
2minutes.
Start the calibration.
Insert the O2 sensor back in the cover of
the inspiratory valve.
Calibrate the flow sensor.
