Supplement Fabius plus XL SW 3.n 41
Technical data
Breathing system
The following data have been added:
Alarm for low oxygen supply pressure
The alarm limit has changed:
Compliance
including ventilator hose (without breathing
hoses)
0.8 mL/cmH
2O (0.8 mL/hPa) at 30 hPa
Flexible arm for breathing bag (optional)
Volume 0.13 L
Compliance 0.13 mL/cmH
2O (0.13 mL/hPa) at 30 hPa
Rigid arm for breathing bag (optional)
Volume 0.11 L
Compliance 0.11 mL/cmH
2O (0.11 mL/hPa) at 30 hPa
Resistance
Peak flow
[L/min]
Resistance
[cmH
2O (hPa)]
Inspiratory Expiratory
In accordance with ISO 80601-2-13, dry, with
adult breathing hose set M30146
1)
1) Depending on the ventilation settings, the indicated values may deviate by ±0.3 cmH2O (0.3 hPa).
60 -4.7 4.4
30 -0.6 4.2
15 0.4 3.4
In accordance with ISO 80601-2-13, dry, with neo-
natal breathing hose set M33681
1)
2.5 1.0 2.9
In accordance with ISO 80601-2-13, dry, without
hoses
1)
60 -3.7 3.7
Alarm limit Warning signal (continuous tone for 10 seconds,
adjustable from approx. 61 dB(A) to 74 dB(A)), as
soon as the pressure drops below 20 ±6 psi (1.35
±0.4 kPa x 100).
