10 Dräger Interlock 5000/7000
Installation
3.4.3 Stromlaufplan
00233352_de.ep
s
Zündschalter
Anlassermotor
Anlasserrelais
Unterbrechung
M
V +
V -
Anlasserrelais
(Klemme 50)
Zündung
(Klemme +15, Position 2)
Zubehör
Aus
Plus
Power
braun grau
rot
schwarz
blau
Masseanschluss
(Klemme 31)
®
Dräger
Interlock 5000/7000
Steuereinheit
®
Dräger Interlock 5000/7000
Handteil
Anlasserrelais-Anschluss
Zündungs-Anschluss
Plus-Anschluss (Klemme 30)
OK
