32 Dräger Interlock 5000/7000
Disposal
3.12 Instrument setting and calibration
This work is only permitted to be carried out by an authorized Dräger-
Interlock service centre.
If required, set the variable device settings on the device.
Calibrate the device, if necessary.
3.13 Removing the Interlock 5000/7000
3.13.1 Disconnecting the vehicle battery
Disconnect the earth lead from the vehicle battery before doing
any work.
3.13.2 Detaching the connecting leads
1. Detach the positive lead (red), earth lead (black), ignition lead (blue),
and the door contact lead (white) on the control unit from the cable
harness of the vehicle.
2. If required, also disconnect the control unit's horn, headlights and
D+ lines from the vehicle's cable harness.
3. Protect open leads of the cable harness against short circuit and
corrosion with high-quality insulating tape or thermo shrinkable
tubing.
4. Disconnect the control unit's starter relay lines (grey and brown)
from the vehicle's cable harness and join the two starter relay lines
of the cable harness via soldering.
5. Protect the connection against short-circuit and corrosion,
e. g. using a thermo-shrinkable tubing.
6. After removing the device, re-connect the vehicle battery.
4 Disposal
Dispose of the product in accordance with the applicable rules and
regulations.
4.1 WEEE
NOTICE
Disconnecting the vehicle battery may erase battery-dependent
instrument settings (e. g. the theft code for the radio or the preset
stations). On some vehicles, disconnecting the vehicle battery
may turn the airbag light on, which can then only be turned off by
the vehicle manufacturer.
i
i
In accordance with EU Directive 2002/96/EC this product
must not be disposed of as household waste. This is indicated
by the adjacent icon.
You can return this product to Dräger free of charge.
For information please contact the national marketing
organizations and Dräger.
