Dräger Interlock 5000/7000 13
Installation
Anschlussalternative A: Anschlussalternative B:
00333352_de.eps
gelb
+12V/24 V
Hupenschalter
Hupe
weiß
Positiver Schalter
Sicherung (optional)
Sicherung
Dräger
Interlock® 7000
Hupen-Relais
00433352_de.eps
+12V/24 V
Hupenschalter
Hupe
weiß
gelb
Negativer Schalter
Sicherung
Sicherung (optional)
Dräger
Interlock® 7000
Hupen-Relais
