Jaundice Meter Instructions for Use (MU01380) Page 2 - 7
SPECIFICATIONS
E Ready lamp Illuminates to indicate that the Jaundice Meter
is ready for the next measurement.
F Strap attachment area Is where the strap attaches.
G Reset button Deletes the currently displayed measured
value and prepares for the next measurement.
When used with the Power switch, the device
switches to Check Mode and changes the unit
of measurement.
H DC plug Connects the charger’s DC jack to the unit.
NOTE:
Choose the appropriate power cord
adapter for country of use.
I Checker cover Covers the checker. Open this checker cover
to check the Jaundice Meter.
J DC jack Connects the AC adapter to the charger.
K Charger lamp Illuminates to indicate that the Jaundice Meter
is charging.
L Charger jack Connects the main body to the charger.
M Standard checker
values
For reference.
N Checker Checks for the intensity of light output by tak-
ing measurements in Check Mode.
Name Function
