16 Reprocessing instructions | Perseus A500
Reprocessing
1. Unfasten and pull out the expiratory port (A).
2. Remove the expiratory flow sensor (B).
3. Unfasten and pull off the inspiratory port (C).
4. Remove the inspiratory flow sensor (D).
Removing the upper part of the breathing system
1. To unlock, turn the 3 levers (A) counterclockwise by approx. 120°.
38831
NOTE
When the flexible breathing bag arm is used, there is no bag elbow fitted to the
lower part of the breathing system.
38678
