44 Reprocessing instructions | Perseus A500
Reprocessing
● Plug the breathing circuit (A) into the ports on the breathing system. Fit the filters
at positions (B) (option) and (C).
Observe the instructions on configuring the breathing circuit and filters (refer to
the table with recommended hose configurations in the chapter "Assembly and
preparation" in the instructions for use).
Fitting the breathing bag hose with breathing bag
● Connect the breathing bag (A) to the breathing bag hose (B). Place the
breathing bag hose on the bag elbow (C). Hang the breathing bag hanging
downwards on the bag holder.
Or
Connect the breathing bag to the flexible breathing bag arm (option), (see
"Fitting the flexible breathing bag arm (option)", page 41).
4967049671
