HQ_ Technical data
8 Technical data
Measuring range Type XTR 0000, XTR 0001: 0 to 99 %LEL
Type XTR 0010, XTR 0011: 0 to 9.9 %LEL
Type XTR 0090, XTR 0091 with sensing head SE Ex PR / HT ... DQ: 0 to 99 %LEL
Type XTR 0090, XTR 0091 with sensing head SE Ex LC ... DQ: 0 to 9.9 %LEL
Signal transmission to the controller Measuring current of 4 mA to 20 mA
Supply voltage U
n 12 to 30 V DC, nominal 24 V DC, approx. 105 mA at 24 V DC
Power consumption incl. ex-sensor ≤2.5 W
Cable entry for cable diameters between 7 and 12 mm
Conductor cross-section
0.5 to 1.5 mm
2
Dimensions (W x H x D) Type XTR 0000, XTR 0010: approx. 80 x 150 x 60 mm
Type XTR 0001, XTR 0011: approx. 110 x 150 x 60 mm
Weight approx. 600 g (type XTR 0090, XTR 0091: approx. 450 g)
Degree of protection (according to EN
60529)
IP 66
