Description
Issue 5 - June 2005 Page 13 of 64 Pages
Main circuit board
1. Terminals for batteries or external DC input.
2. Connector for display board.
3. Potentiometers for A1 – A3 alarms and display adjustment.
4. Field device connecting terminals.
5. Connector for options circuit board.
1 2
3
4
5
5
