Installation
Issue 5 - June 2005 Page 22 of 64 Pages
Mounting points dimensions (not to scale):
NOTE
Use a hole cutter to make the cable entries. Do not attempt to
“knock out” the cable entries.
AC supply
Connect a permanent AC supply to the device.
If the AC supply to the device is from an AC socket, the maximum allowed length of
cable between the socket and the unit is 3m.
