Description
Issue 5 - June 2005 Page 16 of 64 Pages
Fuses
Display board
The display shows the gas level, or indicates that the gas level exceeds the measuring
range (over-range) or is below the measuring range (under-range).
Examples
Normal gas level display.
Negative display reading. A negative display reading
may be caused by inaccurate calibration or by drift or
temperature effect of the sensor.
0.50
- 0.5
