Configuration and calibration
Issue 5 - June 2005 Page 32 of 64 Pages
For display board with version 1.01 or 2.01 firmware*, set the measuring range using
this table:
SW1
Measuring range DPs
A B C D E
0 - 1 2 OFF OFF OFF OFF OFF
0 - 3 2 ON OFF OFF OFF OFF
0 - 5 2 OFF ON OFF OFF OFF
0 - 8 2 ON ON OFF OFF OFF
0 - 10 2 OFF OFF ON OFF OFF
0 - 20 1 ON OFF ON OFF OFF
0 - 25 1 OFF ON ON OFF OFF
0 - 30 1 ON ON ON OFF OFF
0 - 50 1 OFF OFF OFF ON OFF
0 - 100 1 ON OFF OFF ON OFF
0 - 200 0 OFF ON OFF ON OFF
0 - 250 0 ON ON OFF ON OFF
0 - 300 0 OFF OFF ON ON OFF
0 - 500 0 ON OFF ON ON OFF
0 - 1000 0 OFF ON ON ON OFF
0 - 2000 0 ON ON ON ON OFF
0 - 2500 0 OFF OFF OFF OFF ON
0 - 3000 0 ON OFF OFF OFF ON
0 - 5000 0 OFF ON OFF OFF ON
0 - 9999 0 ON ON OFF OFF ON
DPs decimal places
