Dräger REGARD-1 - Alarm Threshold Voltage Mapping (0-100)

Configuration and calibration
Issue 5 - June 2005 Page 44 of 64 Pages
Use this table to set the alarm threshold. Measure the voltage across TP1 and TP2
corresponding to the required alarm threshold.
Alarm threshold
(% of 0 – 100 range)
Voltage across TP1 & TP2 (V)
5% 0.96
10% 1.12
15% 1.28
20% 1.44
25% 1.60
30% 1.76
35% 1.92
40% 2.08
45% 2.24
50% 2.40
55% 2.56
60% 2.72
65% 2.88
70% 3.04
75% 3.20
80% 3.36
85% 3.52
90% 3.68
95% 3.84
