Controller Rear Panel Controls and Connectors
Power Connection for the Stand (RW82)
Name Description
Circuit breaker Turns the controller on and off when switched by the operator or
when excessive system current exists.
Power Accepts the AC power cable.
Auxiliary port Data port for connection to a printer or host computer system.
Name Description
Power inlet Accepts the AC power cable.
On/Off switch Switches the device on and off.
Fuse Turns the actuator (RW82 VHA only) off when the presence of
excessive current is detected. Press to reset the actuator.
