Silence/Reset key Has three functions: silences alarms, resets Manual Mode, and
sets procedural silence.
If an alarm sounds in Manual Mode, press to silence the High
Temp alarm for 2 min, reset the Chk Patient alarm, and silence
the Chk Patient alarm at any time after 10 min. If it is not
pressed, the heater turns off after 15 min. Press to restore heater
power.
If an alarm sounds in Baby Mode, press to silence the High Temp
alarm for 2 min or the Baby Temp alarm for 10 min. During non-
alarm conditions, press to enter procedural silence.
Pre-Warm indicator Indicates that the controller is operating in Pre-Warm Mode.
Manual indicator Indicates that the controller is operating in Manual Mode.
Baby indicator Indicates that the controller is operating in Baby Mode.
Mode Select key Press to select Pre-Warm, Manual, or Baby Mode of operation.
NOTE:
Defaults to Pre-Warm upon power up.
Skin probe connector Accepts the skin probe for monitoring the infant skin temperature.
When connected, the Baby Temperature display indicates the
temperature sensed by the probe when in Manual or Baby Modes.
When in Pre-Warm Mode for software version 1.08 or greater, the
display indicates “PrE.” When the probe is disconnected, the
Baby Temperature display goes blank in Manual or Baby Modes
and indicates "PrE" in Pre-Warm Mode. When disconnected in
Baby Mode, the probe alarm also occurs.
Keypad Lock key Deactivates keypad to avoid accidental changes to settings.
Press to deactivate the >37 °C, Up arrow, Down arrow, and Mode
Select keys. The Keypad Lock key illuminates to indicate the
keypad is locked. Press again to activate the keys.
Examination Light key Press to turn the examination light located in the warmer module
on or off.
Name Description
