PROPRIETARY AND CONFIDENTIAL DRAFT 5 Feb 04
2 - 17
Width (Side-to-Side) (WBR82) 71.1 cm (28")
Width (Side-to-Side) (RW82) 74.9 cm (29.5")
Depth (Front-to-Back) (WBR82) (with cart) 121.9 cm (48")
Depth (Front-to-Back) (RW82) 114.3 cm (45")
Weight w/Warmer and Cart (WBR82) 145.1 kg (320 lbs.)
Weight (RW82) 90.7 - 117.9 kg (220 - 260 lbs.)
Weight w/VHA (RW82) 100.0 - 127.3 kg (220 - 280 lbs.)
Weight w/Bracket (WMRW82) 18.1 kg (40 lbs.)
Warmer Head Rotation ±90°
ENVIRONMENTAL
Operating Temperature Range 18°C to 30°C (64.4°F to 86°F) ambient
Storage Temperature Range - 40°C to + 70°C (-40°F to + 158°F) ambient
Relative Humidity Operating Range 5% RH to 95% RH, non-condensing
Feature Dimension
