Dräger RW82 - Assembly of the Resuscitaire Wall Mounted Radiant Warmer (WMRW82)

PROPRIETARY AND CONFIDENTIAL DRAFT 5 Feb 04
4 - 10
Assembly of the Resuscitaire Wall Mounted Radiant Warmer (WMRW82)
WARNING:
The wall mount bracket installation must be appropriately certified that it meets or exceeds the
pull-out force prior to mounting the Resuscitaire Wall Mounted Radiant Warmer. Failure to do so
can result in an unsafe installation that could cause equipment damage or personal or patient
injury.
NOTE:
Due to space constraints, the Resuscitaire Wall Mounted Radiant Warmer should be fully assembled
(except the wall mount cover plate) before it is mounted on the wall.
1. Remove the back cover from the modified post.
2. Remove the controller from the modified post.
3. Mount the modified post on the wall mount bracket
using the wall mount plates, the 1/4 - 20 x 3/4” cap
screws, and the lock washers in the front holes, and the
1/4 - 20 x 7/8” cap screws, and the lock washers in the
rear holes.
