Connection of the relay output
During operation
During operation the values for each gas detected are
displayed on the inserted Dräger X-am 5x00.
The visual and acoustic life signal (LED ring green and
single tone) is issued depending on the configuration
(1 - 60 seconds; default setting every 2 seconds). The
life signal can be configured using the Dräger CC-Vision
PC software (refer to “Device configuration” on
page 14).
In the event of an alarm, the visual and the audible
alarm will be activated (refer to “Alarms (default
settings)” on page 11).
The Dräger X-zone 500 will amplify the visual and
audible alarm and will permanently transmit the alarm
information, via a wireless connection or via cable, to
further Dräger X-zone 5000 devices.
Alarms (default settings)
The Dräger X-zone 5000 is equipped with two different
alarm generators:
– Visual signal: LED ring (360°);
Colours red, green; pulsing.
– Acoustic signal: Intense horn (108 dB (A) in 1 m
distance/120 dB (A) in 30 cm distance).
Triggering device:
As soon as a device detects an increased gas
concentration, this device will become the triggering
device.
The triggering device forwards the alarms to all
connected devices wirelessly and/or via communication
cable.
Receiving device:
All devices that receive an alarm from the triggering
device become receiving devices. The receiving
devices generate a seconary alarm. If the receiving
device does not receive any information from the
triggering device, the secondary alarm on the receiving
devices is cancelled after 10 seconds.
Maximum voltage (U
i
): 20 V
Maximum continuous current
(I
i
):
0.15 A
Maximum switching capacity
(P
i
):
3W
For ohmic loads only:
Reactances: C
i
≤ 100 pF L
i
≤ 10 µH
NOTICE
The displays on the Dräger X-am 5x00 are described in
the instructions for use for the gas detection instrument
being used.
NOTICE
The alarm settings (e. g. self-latching/
acknowledgeable) can be configured using the Dräger
CC-Vision PC software. The configuration of the
Dräger X-am 5x00 is critical for the correct response of
the Dräger
X-zone 5000.
NOTICE
The alarm-triggering device and the receiving devices
give a different visual alarm.
DRAFT 02 - 08/02/10
