Dräger X-zone 5000 User Manual

18
Fault messages
Special symbol » « and
displayed numerical
code:
Cause Remedy
01 Dräger X-am 5x00 with alkali supply unit. Insert Dräger X-am 5x00 with battery
power pack.
02 Communication interrupted with
Dräger X-zone 5000.
Check IR interface on Dräger X-zone
5000 and on Dräger X-am 5x00.
03 Communication error with battery
controller
Dräger X-zone 5000.
Contact Dräger service department.
04 Main battery alarm Dräger X-am 5x00. Check charging contacts on Dräger X-
zone 5000 and on Dräger X-am 5x00.
05 Battery pre-alarm Dräger X-am 5x00. Check charging contacts on Dräger X-
zone 5000 and on Dräger X-am 5x00.
06 Dräger X-am 5x00 charging current too
low.
Check charging contacts on Dräger X-
zone 5000 and on Dräger X-am 5x00.
07 Holder (pump) detected, but no pump
fitted.
Use holder for diffusion mode.
08 Flow fault Check intake hose.
09 Holder status change (pump) during
operation.
Check that the holder (pump) is securely
positioned.
10 Check sum error program code Contact Dräger service department.
11 Check sum error operating parameter Contact Dräger service department.
12 Check sum error operating parameter Contact Dräger service department.
13 Check sum error operating parameter Contact Dräger service department.
14 Working memory test error Contact Dräger service department.
15 Faulty ADC conversion. Contact Dräger service department.
16 No contact with switch box in grouping
mode.
Check wireless connection to switch box.
17 Charging electronics faulty. Contact Dräger service department.
18 Battery completely discharged. Charge Dräger X-zone 5000.
19 Battery main alarm of the Dräger X-zone
5000.
Charge Dräger X-zone 5000.
20 Battery pre-alarm of the Dräger X-zone
5000.
Charge Dräger X-zone 5000.
21 Dräger X-am5x00 device error. Check Dräger X-am 5x00.
22 Dräger X-am5x00 alarm pattern faulty. Contact Dräger service department.
23 - X28 - -
29 Battery main alarm Charge Dräger X-zone 5000.
30 Battery completely discharged. Charge Dräger X-zone 5000.
31 Charging electronics faulty. Contact Dräger service department.
32 Communication error with battery
controller
Dräger X-zone 5000.
Contact Dräger service department.
