LED Status Explanation
Blinking The rout er is ready and operat ing normally
(Act ivit y)
Of f The rout er is powered of f
On DSL connect ion synchronised
Blinking
(Slowly)
DSL connect ion not current ly synchronizing or
not det ect ed
(DSL)
Blinking
(Quickly)
DSL connect ion is synchronising
On (Green) 2. 4GHz Access Point is act ive
Blinking
(Green)
Dat a is being t ransmit t ed on t he rout er’ s 2. 4
GHz wireless int erf ace
Blinking
(Orange)
WPS pairing mode is act ive f or t wo minut es
(Wireless LAN
On/ Of f / WPS)
Of f 2. 4GHz Access Point is t urned off
On (Green) 5GHz Access Point is act ive
Blinking
(Green)
Dat a is being t ransmit t ed on t he rout er’ s 5GHz
wireless int erf ace
(Wireless LAN
On/ Of f / WPS)
Blinking
(Orange)
WPS pairing mode is act ive f or t wo minut es
On Et hernet LAN (RJ45) is connect ed
Blinking Dat a is t ransmit t ing (sending/ receiving)
~
(LAN1/ 2/ 3/ 4)
Of f Et hernet LAN is disconnect ed
On USB device is connect ed and ready for use
(USB)
Blinking Dat a is being t ransmit t ed over USB
