LED Status Explanation
Blinking The rout er is ready and operat ing normally
(Act ivit y)
Of f The rout er is powered of f
On DSL connect ion synchronised
Blinking
(Slowly)
DSL connect ion not current ly synchronising or
not det ect ed
(DSL)
Blinking
(Quickly)
DSL connect ion is synchronising
On The phone connect ed t o t his port is of f -hook
Of f The phone connect ed t o t his port is on-hook
Blinking A phone call is incoming
On (Green) 2. 4GHz Access Point is act ive
Blinking
(Green)
Dat a is being t ransmit t ed on t he rout er’ s 2. 4
GHz wireless int erf ace
Blinking
(Orange)
WPS pairing mode is act ive f or t wo minut es
(Wireless LAN
On/ Of f / WPS)
Of f 2. 4GHz Access Point is t urned off
On (Green) 5GHz Access Point is act ive
Blinking
(Green)
Dat a is being t ransmit t ed on t he rout er’ s 5GHz
wireless int erf ace
Blinking
(Orange)
WPS pairing mode is act ive f or t wo minut es
(Wireless LAN
On/ Of f / WPS)
Of f 5GHz Access Point is t urned of f
On Et hernet LAN (RJ45) is connect ed
Blinking Dat a is t ransmit t ing (sending/ receiving)
~
(LAN1/ 2/ 3/ 4)
Of f Et hernet LAN is disconnect ed
On USB device is connect ed and ready for use
(USB)
Blinking Dat a is being t ransmit t ed over USB
