Draytek VigorPhone 350 - Back View

12
1
1
.
.
2
2
.
.
2
2
B
B
a
a
c
c
k
k
V
V
i
i
e
e
w
w
Item Name Description
1 Handset Jack Connects to the phone. RJ-9
2 Headset Jack Connects to an external headset.RJ-9
3 LAN/ PoE Port Connects to LAN cable. 10/100Mbps RJ-45 port for LAN (uplink)
connection. If you are using Power over Ethernet (PoE), the power to
the phone is supplied when you connect the Ethernet cable. Draws
power from either spare line or signal line.
4 PC Port Connects to PC. 10/100Mbps RJ-45 port for PC (downlink)
connection.
5 Power Jack Connects to AC power adapter. 12V DC power port.
