DEHUMIDIFIER INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Models, capacities, and electrical specifications
Table 10-1:
RL Series Specifications
Model RL-3 Model RL-4 Model RL-6 Model RL-9 Model RL-14 Model RL-31
Capacity
(1)
70 pints/day
(3 lb/hour)
100 pints/
day
(4 lb/hour)
130 pints/
day
(6 lb/hour)
210 pints/day
(9 lb/hour)
320 pints/day
(14 lb/hour)
340 pints/
day
(15 lb/
hour)
710 pints/day (31 lb/hour)
Voltage
120 VAC,
1 Phase,
60 HZ
120 VAC,
1 Phase,
60 HZ
120 VAC,
1 Phase,
60 HZ
208-240 VAC,
1 Phase,
60 HZ
208-240 VAC,
1Phase,
60 HZ
277 VAC,
1Phase, 60
HZ
208-240 VAC,
1 Phase,
60 HZ
277 VAC,
1Phase,
60 HZ
Operating
Current
(1)
5.8A
240 VAC
6.9A
240 VAC
8.3A
240 VAC
8.6A
240 VAC
11.1A
240 VAC
9.2A
277 VAC
19.6A
240 VAC
17.4A
277 VAC
Rated Current - - - - 20 amp breaker
24A (install on dedicated
30A circuit)
Efficiency
(1)
2.1 L/kWh
(4.4 pints/
kWh)
2.6 L/kWh
(5.5 pints/
kWh)
2.8 L/kWh
(5.9 pints/
kWh)
2.9 L/kWh
(6.1 pints/
kWh)
2.9 L/kWh
(6.1 pints/
kWh)
2.5 L/kWh
(5.3 pints/
kWh)
3.0 L/kWh
(6.3 pints/kWh)
Recommended
Breaker Size
15A 15A 15A 15A 20A 20A 30A 30A
Recommended
Wire Gauge
14 AWG,
Copper
14 AWG,
Copper
14 AWG,
Copper
14 AWG,
Copper
12 AWG,
Copper
12 AWG,
Copper
10 AWG,
Copper
10 AWG,
Copper
Maximum Fuse
or Breaker Size
(MOC)
- - - 19A 30A or lower
25A or
lower
40A at 208V
35A at 240V
30A
Minimum Circuit
Ampacity (MCA)
- - - 11A
21.9A at
208V
18.5A
28A at 208V
25A at 240V
21A
Operating
Temperature
Range
50°F to 104°F (10°C to 40°C), 60°F/40% RH to 85°F/80% RH (15.6°C/40% RH to 25.9°C/80% RH)
(ideal conditions for unit to not go into defrost or shut down due to high pressure)
Operating Dew
Point Lower Limit
40°F (4°C) 36°F (2°C)
Operating
Weight
56 lbs
(25 kg)
64 lbs
(29 kg)
98 lbs
(45 kg)
85 lbs
(39 kg)
180 lbs (82 kg) 360 lbs (163 kg)
Shipping Weight
84 lbs
(38 kg)
87 lbs
(40 kg)
129 lbs
(59 kg)
118 lbs
(54 kg)
214 lbs (97 kg) 385 lbs (175 kg)
Drain Size 3/4" FNPT
Filter
(MERV 11)
8" x 11.75"
x 1"
11.88" x
13.5" x 1"
14" x 19"
x 1"
14" x 18"
x 2"
20"x22"x2" 30" x 32" x 2"
Airflow @0.0"
ESP
200 CFM
(340 m
3
/h)
280 CFM
(476
m
3
/h)
310 CFM
(527 m
3
/h)
525 CFM
(892 m
3
/h)
830 CFM (1410 m
3
/h) 1760 CFM (2990 m
3
/h)
Power cord Units shipped with 8' (2.43 m) power cord Units shipped with 10' (3.05 m) power cord or can be hard wired.
Dehumidifier
control
50°F and 104°F (10°C to 40°C) cut off
External control On/off dry contact
(1)
Rated capacity and energy factor test done and current draw measured in accordance with AHAM DH-1 2008 at 80°F (26.7°C), 60% RH inlet
air at 0.0 ESP.
