4
DEHUMIDIFIER INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
ON/OFF button
used to turn
dehumidifier on
and off
Up/Down
buttons used
to change
humidity setting
MODE button
used for
optional features
Product overview
OVERVIEW
FIGURE 4-1: DEHUMIDIFIER CONTROL
FIGURE 4-2: MODEL RL-3 DEHUMIDIFIER
Inlet
Filter Access Door
Drain
Dehumidifier Control Outlet
FIGURE 4-3: MODEL RL-4 DEHUMIDIFIER
Dehumidifier Control
Inlet Filter
Access Door
Drain
Outlet
