DEHUMIDIFIER INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
FLOOR MOUNTING
The leveling feet kit (if included) is required for floor mounting. The drain hose/
pipe must continuously slope downward toward the drain. Use solid supports
as needed to elevate the unit enough to allow for continuous drain slope. Use
the adjustable feet to level the unit right to left and front to back so that unit
drains properly.
Mounting
INSTALLATION
FIGURE 16-1: RL-14 FLOOR MOUNTING USE LEVEL FEET KIT (PART #601175)
90-2443
90-2438
Blocking must be used for p-trap clearance
3-1/4" (83 mm)
Brackets
(Included)
Leveling
feet (sold
separately)
