57
DEHUMIDIFIER INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
REPLACEMENT PARTS
Table 57-1:
Model RL-6 replacement parts and accessories
Part
number Part Description Part No.
1 FILTER,MERV 11,RL-6 601249
2 CNTRL,PCB,RL-14-9-6-4-3 601190
3 UI,RL-14-9-6-4-3 601197
4 HOLE COVER,UI CTRL,RL-6-4 601255
5 DOOR, FILTER ACCESS,RL-6 601266
6 OUTLET DUCT PANEL,RL-6-4 601256
7 BACKFLOW DAMPER,RL-6-4 601257
8 INLET DUCT PANEL,RL-6-4 601258
9 COVER,OUTLET,RL-6-4 601259
10 FAN,W. CAPACITOR,RL-6 601267
11 WIRE HARNESS,POWER,RL-6-3 601260
12 SENSOR,LO TEMP,RL-9-6-4-3 601261
13 SENSOR,HI TEMP,RL-6-4-3 601262
14 LVL FEET KIT,RL-9-6-4-3 601263
15 CAPACITOR,CMPRSSR,RL-6 601287
16 CAPACITOR,RL-6 601268
17 DRAIN W. FTG,RL-6-4-3 601272
18 SWITCH,CMPRSSR OL,RL-6 601269
Not Shown
D77 DIGITAL DEHUMIDIFIER CNTRL 601171
HUMIDISTAT DEHUM BACNET ROOM KIT 601180
HUMIDISTAT DEHUM BACNET DUCT KIT 601182
ALERT LIGHT, RL 601176
HANGING KIT,RL-6 601300
CONDENSATE PUMP KIT,RL 601288
Model RL-6
