DriSteem RL-3 - Dimensions

12
DEHUMIDIFIER INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
FIGURE 12-2: MODEL RL-4 DEHUMIDIFIER DIMENSIONS
Dimensions
FIGURE 12-1: MODEL RL-3 DEHUMIDIFIER DIMENSIONS
90-2289_RL-3
90-2612
BACK
TOP
34 (864 mm)
10
(254 mm)
26 (660 mm)
4 (102 mm)
1.25 to 2
(32 to 50 mm)
BACK
TOP
32.88 (835 mm)
4 (102 mm)
ø0.75 (20 mm)
pipe inside
4
(102 mm)
0.38 to 2 (10 to 50 mm)
ø0.75 (20 mm) pipe inside
4 (102 mm)
14 (356 mm)
10
(254 mm)
24.88 (632 mm)
8
(203 mm)
12.5
(318 mm)
12.5 (318 mm)
8
(203 mm)
15
(381 mm)
SPECIFICATIONS
