55
DEHUMIDIFIER INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
REPLACEMENT PARTS
Table 55-1:
Model RL-4 replacement parts and accessories
Part
number Part Description Part No.
1 FILTER,MERV 11, RL-4 601253
2 CNTRL,PCB,RL-14-9-6-4-3 601190
3 UI,RL-14-9-6-4-3 601197
4 UI COVER,RL-14-9-6-4-3 601254
5 HOLE COVER,UI CTRL,RL-6-4 601255
6 DOOR,FILTER ACCESS,RL-4 601283
7 OUTLET DUCT PANEL,RL-6-4 601256
8 BACKFLOW DAMPER,RL-6-4 601257
9 INLET DUCT PANEL,RL-6-4 601258
10 COVER,OUTLET,RL-6-4 601259
11 FAN W. CAPACITOR,RL-4 601286
12 WIRE HARNESS,POWER,RL-4 601284
13 SENSOR,LO TEMP,RL-9-6-4-3 601261
14 SENSOR,HI TEMP,RL-6-4-3 601262
15 LVL FEET KIT,RL-9-6-4-3 601263
16 CAPACITOR,RUN,RL-4 601271
17 CAPACITOR,RL-4 601265
18 DRAIN INSERT,RL-4 601285
19 DRAIN W. FTG,RL-6-4-3 601272
Not Shown
D77 DIGITAL DEHUMIDIFIER CNTRL 601171
HUMIDISTAT DEHUM BACNET ROOM KIT 601180
HUMIDISTAT DEHUM BACNET DUCT KIT 601182
ALERT LIGHT, RL 601176
HANGING KIT,RL-4-3 601299
CONDENSATE PUMP KIT,RL 601288
Model RL-4
