DEHUMIDIFIER INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
REPLACEMENT PARTS
Table 63-1:
Model RL-31 replacement parts and accessories
Part
number Part Description Part No.
1
TRANSFORMER,RL-31-14-9 601156-001
TRANSFORMER,40VA,RL,277 601156-002
2 FUSE,3AB,.4A 440V SLWBLW,RL-31 601157
3 INTERNAL POWER PCB, RL-31 601158
4 CONTACTOR,CMPR,RL-31-14-9 601159
5 FAN RELAY,RL-31-14-9 601160
6 FAN ASSEMBLY, RL-31 601161
7
CORD,SJT 10/3,L6-30P,RL-31,208-240 601162-001
CORD,SJT 10/3,L7-30P,RL-31,277 601162-002
8 FILTER, MERV 11, RL-31 (QTY 6) 601163
9 USER INTERFACE, RL-31 601164
10 SENSOR, LOW TEMP, RL-31 601165
11 SENSOR, HIGH TEMP, RL-31 601166
12
MOV BOARD, RL-31, 204-240 601167-001
MOV BOARD, RL-31, 277 601167-002
13
EMI FILTER BOARD,RL-31,208-240 601168-001
EMI FILTER BOARD, RL-31,277 601168-002
14
COMP DRIVE BRD, RL-31,208-240 601169-001
COMP DRIVE BRD, RL-31,277 601169-002
15 CHOKE-COMPRESSOR DRIVE, RL-31 601170
Not Shown
D77 DIGITAL DEHUMIDIFIER CNTRL 601171
HUMIDISTAT DEHUM BACNET ROOM KIT 601180
HUMIDISTAT DEHUM BACNET DUCT KIT 601182
P-TRAP KIT, RL-31,RL-14 601172
FTG,3/4"MNPT X 3/4"BARB,PVC,RL 601173
TUBING,DRAIN,RL-31-14-9 601174
LEVELING FEET, RL 601175
ALERT LIGHT, RL 601176
DUCT KIT, RL-31 601177
CONDENSATE PUMP KIT,RL 601288
