39
DEHUMIDIFIER INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
INSTALLATION
90-2535
FIGURE 39-3: RL-31 HARD WIRING TO
REPLACE THE POWER CORD
L1
BLK
L2
WHT
GND
GND
L1
BLK
L2
WHT
GND
GND
90-2401
FIGURE 39-1: RL-9 HARD WIRING TO REPLACE THE POWER CORD
Hard wire - line voltage (RL-9, RL-14, and RL-31 only)
L1 L2 G
L1 L2 G
90-2439
FIGURE 39-2: RL-14 POWER CORD
WIRING
Connect the line
(blk) and neutral
wire (wht) wires to
the power block.
Connect
the bare
or green
ground
wire to the
ground
lug
Disconnect
power cord
wires
Electrical
service panel
Hard wiring
access
Disconnect power
cord wires
MOV board
Connect the line (blk)
and neutral (wht)
wires to move board
as shown
Connect
ground to lug
Electrical
service panel
Hard
wiring
access
Disconnect
power
cord wires
Connect
the line
(BLK) and
neutral
(WHT)
wires
to the
power
block
Connect the bare or
green ground wire
to the ground lug
