Owner's Manual
Drivecon Toll Free Ph: 1-800-374-8266
Drivecon reserves the right to alter or amend the above information without notice
NXOPTA3 this card plugs into slot B. Standard.
No. Name Description, signal level No. Name Description, signal level
21 ROB1 NC contact of ROB1 25 ROB2 NO contact of ROB2 (brake relay)
22 ROB1 C contact of ROB1 26 ROB2 C contact of ROB2 (brake relay)
23 ROB1 NO contact of ROB1 28 T1 Thermistor input 1
29 T2 Thermistor input 2
D-9
